Military Temperature Humidity Chamber , Constant Temperature And
Humidity Chamber 30% Energy Saving
Model | TH-80 (A~F) | TH-150 (A~F) | TH-22 5(A~F) | TH-40 8(A~F) | TH-800 (A~F) | TH-1 000(A~F) |
Internal Dimension WxHxD (mm) | 400x 500x400 | 500x 600x500 | 600x 750x500 | 600x 850x800 | 1000x 1000 x800 | 1000 x1000x 1000 |
External Dimension WxHxD (mm) | 950x 1650x950 | 1050x 1750x1050 | 1200 x1900x1150 | 1200 x1950x1350 | 1600 x2000x1450 | 1600 x2100x1450 |
Temperature Range | Low Temperature(A:25°C B:0°C C:-20°C D:-40°C E:-60°C F:-70°C)
High Temperature 150°C |
Humidity Range | 20%~98%R.H.(10%-98% R.H. / 5%-98% R.H.,is optional , need
Dehumidifier) |
Distribution Uniformity
of temperature and humidity | ±2.0°C; ±3.0% R.H. |
Control Accuracy
of Temp. and Humi. | ±0.5°C; ±2.5% R.H. |
Temperature
Humidity Control
Chart |
|
Temperature Rising
/Falling Velocity | Rising approx. 0.1~3.0°C/min;
Falling approx. 0.1~1.5°C/min; ( Falling >1.5°C/min is optional) |
Inner and Outer
Material | Interior is SUS 304# stainless steel, exterior is stainless steel
or see cold-rolled steel with paint coated. |
Insulation Material | Resistant to high temperature, high density, formate chlorine, ethyl acetum foam insulation materials |
Cooling System | Wind cooledor water cooled; single segment compressor for -40°C, double segment compressor for -70°C |
Protection Devices | Fuse-free switch, overloading protection switch for compressor, high and low voltage coolant protection switch, over-humidity and over-temperature protection switch, fuses, fault warning system, water short storage warning protection |
Optional Accessories | Inner door with operation hole , Recorder, Water Purifier,
Dehumidifier |
Compressor | French Tecumseh Brand, Germany Bizer Brand |
Power | AC220V 50/60HZ , AC380V 50/60HZ |
Weight (Kg) | 150 | 180 | 250 | 320 | 400 | 450 |
30% Energy saving Military constant temperature and humidity
chamber Features :
1. Graceful appearance, circularly shaped body, surface treated
with mist strips,.
2.Rectangular double-paned viewing window for the observation of
sample under test,with interior lights.
3. Double-layer-insulated airtight doors, able to insulate the
internal temperature effectively.
4. Water supply system that is externally connectable, convenient
for refilling water into the humidifying pot
and
automatically recyclable.
5. French Tecumseh brand is used as compressor, with environment
friendly refrigeration R23,R404A.
6. LCD display screen is used for the control unit, capable of
displaying set point and actual value at
the same time
7. The control unit has the functions of multiples segment program
editing, and of quick or ramp rates
control of
temperature and humidity.
8. Casters are provided for ease of mobility, with strong
positioning screws.
30% Energy saving Military constant temperature and humidity
chamber Applications:
constant temperature and humidity stability Test Chamber used to
test various types of materials for their tolerances of heat, cold,
dry, humidity. It is applied for for all types of electronic
products,electric appliance, and products from communication,
instrument, automobile, plastic, metal, food, chemical,building
materials, medical and aerospace industries.
